By TEIKOKU
Supplier Info
Product Type:
Equipment
Application:
(De-)Taping, Mounting, Curing
Product Description:
Laser Cutting with heating roller and table and digitally adjustable high pressure performance.
- Removes tape from wafers up to 200mm (4-,5-,6-, and 8-inch)
- Parameters for de-taping can be controlled in the recipe
- Longer-lasting UV lamp realized by TTS’s proprietary UV technology
- Also suitable for ultra-thin wafers
- Removing type: Sticky or Heat Seal
- Several features are available
Machine Utilities
| Power: | AC200-240V,Single Phase |
| Power Consumption: | 2KVA (without UV) / 3KVA (with UV) |
| Clean Air Pressure (CDA): | 0.5 – 0.6 MPa (Min Flow Rate: 120NL/min) |
| Vacuum | 650 – 750mm Hg (Min Flow Rate: 60NL/min) |
| Nitrogen (for UV) | 0.2 – 0.4 MPa (Min Flow Rate: 20NL/min) |
| Exhaust Duct Capacity | 1.0m3/min, 10mmH20 (100mm diameter SUS Flange duct connection) |
System Arrangement
| Dimension (WxDxH) | 1250×1400×2000mm |
| Net Weight | Appx 600Kg |
There are currently no downloads available.
Laser Cutting with heating roller and table and Digitally adjustable high pressure performance designed for Bumping, wafer level CSP manufacturing and special MEMS manufacturing process.
